HUW500 Ultrasonic Spot Welding Machine

The HUW500 family of low power systems is Sewsonic’s latest offering for applications with power requirements of 500 Watts or less. The HUW500 units can be used with their appropriate hand-held devices or can be connected directly to a converter / booster / horn stack for use in automation.

An ultrasonic spot welding machine in accordance with ergonomics is arranged on the basis of the handheld welder. It is primarily used for point-ny-point riveting, welding and molding of thermoplastic. With the modular integrated circuit, it has strong output power and is easy for operation. The built-in fully-automatic protection circuit ensures safe application and stable and reliable operation.

• Multifunctional ultrasonic series models, different from the kind of electric iron plug type, when in operation.
• Simple to used no need for glue or solder, welding time can be adjusted or manual controlled.
• Low power consumption, strong effect, low noise small volume.
• Pistol type&straight staple type guns available.
• Easy grip guns available with less diameter
• High quality connectors used to lessen loose connections
• Available in below frequencies: 20kHz & 30kHz & 35kHz & 40kHz

• Power Rating: 500watts
• Frequency: 40kHz
• Dimensions: 380x285x140mm
• Voltage: 110v, 50/60Hz/220V

• Generator
• Power cable
• Converter
• Converter cable
• Probe
• Wrench set

The hand-held ultrasonic welders are compact, lightweight tools used to spot weld or stake large, complex parts and those with hard-to-reach joint areas.

With pistol grip models, the trigger switch is located on the grip; barrel grip models have the trigger switch located on the side of the barrel. All units may be operated in an untimed mode with the FZ1000A set for continuous operation, utilizing the trigger switch; or in a timed or energy mode using the FZ1000A power supply controller.
