HLC300 Ultrasonic Linear Cutting Structure

The HLC300 ultrasonic unit has been developed by Sewsonic for cutting manually various types of synthetic fabrics in a fast, efficient way. This ultrasonic assembly allows for clean cuts without unwanted fraying, thanks to ultrasonic vibrations, synthetic fabrics are not only cut but their edges are sealed automatically, preventing them from unraveling.

Linear cutting frame: Designed to be easily installed on work benches with the assistance of its two wheels and steel plate treated with a special hardening procedure.

• Plastic handgrips: This kind of hand grip is light and versatile. It was conceived to grant freedom of movement during the synthetic materials slicing process.
• Optional: aluminum sliding rails to be mounted on tables for rectilinear cutting structures.

• Can be used standalone or in production line
• Safe and reliable, save space, clean and free of debris
• Easy to use and easy to use
• Fast cutting, high production speed and profitability
• Will not burn the product, will not produce toxic gases

• Industrial safety: protective suits, sun protection, parachutes, bullet proof vests, awnings, shower curtains, spacer fabrics, seat covers, MBR-modules.
• Fashion/Sportswear: sportswear, swimwear, outdoor garment, bras, lingerie
• Automotive: airbag, vehicle interior and insulation item, car covers
• Hygiene Medical: medical garment, surgical cloths, medical layers, mask, medical mattresses, needle felts, surgical drapes, surgical overlays and surgical clothing

• Model: HLC300
• Output power: 300W
• Bracket Height: 190mm
• Handle Diameter: 32mm
• Moving: bottom sliding
• N.W.: 1.7kg

• Frequency: 40kHz
• Voltage: 220V/50HZ/110V
• Length: 380mm
• Width: 235mm
• Height: 125mm
• N.W.: 3.2kg

• Material of Blade: High-speed steel (optional)
• Ultrasonic system: Can work continuously
• Material of bracket: 6061 aluminum
• Cutting speed: 0-30m/min
• Length of cord: 3m
